Solid Copper Earth Rods
These rods are manufactured from high conductivity copper and are used in application where the soil conditions are very aggressive, i.e. soils with high salt content. These rods offer high corrosion resistance and are internally threaded at both ends for joining the rods using internal threaded coupling dowels.
9 Products
Part No. 138031 ER 15 1200 IM10 CU
GTIN 4013364300767, Customs tariff No. (EU): 85389000, Gross weight: 1.89 kg, PU: 5.00 pc(s)
Technical data
Material | Cu |
Rod length (L) | 1200 mm |
Rod Diameter (D) | 15 mm |
Internal thread size | M10 |
Standards | IEC / BS / EN 62561-2 |
Approvals | DAkkS, VDE |
Part No. 138035 ER 15 1500 IM10 CU
GTIN 4013364493414, Customs tariff No. (EU): 85389000, Gross weight: 2.36 kg, PU: 5.00 pc(s)
Technical data
Material | Cu |
Rod length (L) | 1500 mm |
Rod Diameter (D) | 15 mm |
Internal thread size | M10 |
Standards | IEC / BS / EN 62561-2 |
Approvals | DAkkS, VDE |
Part No. 138038 ER 15 3000 IM10 CU
GTIN 4013364493421, Customs tariff No. (EU): 85389000, Gross weight: 4.72 kg, PU: 5.00 pc(s)
Technical data
Material | Cu |
Rod length (L) | 3000 mm |
Rod Diameter (D) | 15 mm |
Internal thread size | M10 |
Standards | IEC / BS / EN 62561-2 |
Approvals | DAkkS, VDE |
Part No. 138033 ER 16 1200 IM10 CU
GTIN 4013364431164, Customs tariff No. (EU): 85389000, Gross weight: 2.15 kg, PU: 5.00 pc(s)
Technical data
Material | Cu |
Rod length (L) | 1200 mm |
Rod Diameter (D) | 16 mm |
Internal thread size | M10 |
Standards | IEC / BS / EN 62561-2 |
Approvals | DAkkS, VDE |
Part No. 138050 ER 16 1500 IM10 CU
GTIN 4013364493438, Customs tariff No. (EU): 85389000, Gross weight: 2.68 kg, PU: 5.00 pc(s)
Technical data
Material | Cu |
Rod length (L) | 1500 mm |
Rod Diameter (D) | 16 mm |
Internal thread size | M10 |
Standards | IEC / BS / EN 62561-2 |
Approvals | DAkkS, VDE |
Part No. 138051 ER 16 3000 IM10 CU
GTIN 4013364475540, Customs tariff No. (EU): 85389000, Gross weight: 5.37 kg, PU: 5.00 pc(s)
Technical data
Material | Cu |
Rod length (L) | 3000 mm |
Rod Diameter (D) | 16 mm |
Internal thread size | M10 |
Standards | IEC / BS / EN 62561-2 |
Approvals | DAkkS, VDE |
Part No. 138060 ER 20 1200 IM10 CU
GTIN 4013364300712, Customs tariff No. (EU): 85389000, Gross weight: 3.35 kg, PU: 5.00 pc(s)
Technical data
Material | Cu |
Rod length (L) | 1200 mm |
Rod Diameter (D) | 20 mm |
Internal thread size | M10 |
Standards | IEC / BS / EN 62561-2 |
Approvals | DAkkS, VDE |
Part No. 138062 ER 20 1500 IM10 CU
GTIN 4013364493445, Customs tariff No. (EU): 85389000, Gross weight: 4.19 kg, PU: 5.00 pc(s)
Technical data
Material | Cu |
Rod length (L) | 1500 mm |
Rod Diameter (D) | 20 mm |
Internal thread size | M10 |
Standards | IEC / BS / EN 62561-2 |
Approvals | DAkkS, VDE |
Part No. 138063 ER 20 3000 IM10 CU
GTIN 4013364493452, Customs tariff No. (EU): 85389000, Gross weight: 8.39 kg, PU: 5.00 pc(s)
Technical data
Material | Cu |
Rod length (L) | 3000 mm |
Rod Diameter (D) | 20 mm |
Internal thread size | M10 |
Standards | IEC / BS / EN 62561-2 |
Approvals | DAkkS, VDE |
